Submit ReviewMitoBrilliant™ 646
Description: Universal red fluorescent mitochondrial stain for both live and fixed cells
Purity: ≥95% (HPLC)
Biological Activity for MitoBrilliant™ 646
MitoBrilliant probes have been developed to overcome some common limitations encountered with standard mitochondrial trackers, offering clearer answers to scientific questions. They are next-generation fluorescent stains for the localization and tracking of mitochondria in both live and fixed cells. The range harnesses Janelia Fluor® dye technology, conferring some of the properties that make these widely used dyes, into mitochondrial stains.
Key information: MitoBrilliant™ 646 is a red-fluorescent mitochondrial stain for both live and fixed cells.
Used for: mitochondrial staining for both live and pre-fixed cells/tissue.
Application: flow cytometry, super-resolution microscopy-STED, high content screening, IHC/ICC.
Properties and Photophysical Data: MitoBrilliant™ 646 is retained in mitochondria following fixation with exceptionally clear staining and is retained in the mitochondria of live cells following loss of the mitochondrial membrane potential. Excitation and emission maxima (λ) are 655 nm and 668 nm, respectively; extinction coefficient = 125,000 M-1cm-1.
Two dyes that accumulate in the mitochondria of live cells in a mitochondrial membrane potential (Δψm) dependent manner are also available: MitoBrilliant™ Live 646 (red emission) and MitoBrilliant™ Live 549 (yellow/orange emission).
Please refer to the protocol for guidelines on product use, and download the MitoBrilliant Product Guide to view data for each of the dyes in different applications.
MitoBrilliant is a trademark of Bio-Techne Corp.
Scientific Data
Live-cell Imaging
View Larger
View Larger
Live-cell image of mitochondria stained with MitoBrilliant™ 646 HeLa cells were incubated with MitoBrilliant™ 646 (100 nM) for 40 minutes and counterstained with DAPI (Catalog # 5748). Image was taken using an LSM880 Confocal using a 63x objective. Scale bar = 10 µm.
Fixed-cell Imaging
View Larger
View Larger
Fixed-cell image of mitochondria stained with MitoBrilliant™ 646. Dermal fibroblast cells were incubated with MitoBrilliant™ 646 (100 nM) for 1 hour at 37°C, fixed with ice-cold acetone-methanol (1:1) and counterstained with Hoechst 33342 (Catalog # 5117). Image was taken using an Echo Revolve microscope using a 20x objective. Scale bar = 20 µm.
| Product Name | Core dye structure | Abs/Em (nm) | Δψm dependent | Live/Fixed cell use | Stain pre-fixed cells? | Image without wash step | Demonstrated Applications | MitoBrilliant™ 646 Cat. No. 7700 | Janelia Fluor® technology | 655/668 | No* | Suitable for both live and fixed cell work | Yes | Yes, but replacing media recommended | Fixed-cell imaging, Live-cell imaging, Flow Cytometry, IHC/ICC, Super-resolution microscopy – STED, High-content screening |
|---|---|---|---|---|---|---|---|
| MitoBrilliant™ Live 646 Cat. No. 7417 | Janelia Fluor® technology | 648/662 | Yes | Live-cell work only | No | Yes, but replacing media recommended | Live-cell imaging, Flow Cytometry, High-content screening |
| MitoBrilliant™ Live 549 Cat. No. 7693 | Janelia Fluor® technology | 550/568 | Yes | Live-cell work only | No | Yes, but replacing media recommended | Live-cell imaging, Flow Cytometry, High-content screening |
Optical Data for MitoBrilliant™ 646
| Emission Color | Red |
|---|---|
| λabs | 655 nm |
| λem | 668 nm |
| Extinction Coefficient (ε) | 125000 M-1cm-1 |
| Closest Laser line | 640 nm |
| Application | Fixed-cell imaging, Live-cell imaging, Flow Cytometry, IHC/ICC, Super-resolution microscopy – STED, |
Plan Your Experiments
Use our spectra viewer to interactively plan your experiments, assessing multiplexing options. View the excitation and emission spectra for our fluorescent dye range and other commonly used dyes.
Spectral Viewer
Technical Data for MitoBrilliant™ 646
| M. Wt | 493.55 |
| Storage | Store at -20°C |
| Purity | ≥95% (HPLC) |
The technical data provided above is for guidance only. For batch specific data refer to the Certificate of Analysis.
Tocris products are intended for laboratory research use only, unless stated otherwise.
Solubility Data for MitoBrilliant™ 646
| Solvent | Max Conc. mg/mL | Max Conc. mM | |
|---|---|---|---|
| Solubility | |||
| DMSO | 4.94 | 10 |
Preparing Stock Solutions for MitoBrilliant™ 646
The following data is based on the product molecular weight 493.55. Batch specific molecular weights may vary from batch to batch due to the degree of hydration, which will affect the solvent volumes required to prepare stock solutions.
| Concentration / Solvent Volume / Mass | 1 mg | 5 mg | 10 mg |
|---|---|---|---|
| 0.1 mM | 20.26 mL | 101.31 mL | 202.61 mL |
| 0.5 mM | 4.05 mL | 20.26 mL | 40.52 mL |
| 1 mM | 2.03 mL | 10.13 mL | 20.26 mL |
| 5 mM | 0.41 mL | 2.03 mL | 4.05 mL |
Molarity Calculator
Molarity Calculator
Calculate the mass, volume, or concentration required for a solution.
Reconstitution Calculator
Reconstitution Calculator
Dilution Calculator
Dilution Calculator
Calculate the dilution required to prepare a stock solution.
Product Datasheets for MitoBrilliant™ 646
References for MitoBrilliant™ 646
References are publications that support the biological activity of the product.
If you know of a relevant reference for MitoBrilliant™ 646, please let us know.
View Related Products by Target
Keywords: MitoBrilliant 646, MitoBrilliant 646 supplier, MitoBrilliant, red, fluorescent, mitochondrial, marker, stain, mitotracker, mitochondria, Flow, Cytometry, Mitobrilliant, 7700, Tocris Bioscience
Citations for MitoBrilliant™ 646
Citations are publications that use Tocris products.
Currently there are no citations for MitoBrilliant™ 646. Do you know of a great paper that uses MitoBrilliant™ 646 from Tocris? Please let us know.
Reviews for MitoBrilliant™ 646
Average Rating: 5 (Based on 1 Review.)
Have you used MitoBrilliant™ 646?
Submit a review and receive an Amazon gift card.
$50/€35/£30/$50CAN/¥300 Yuan/¥5000 Yen for first to review with an image
$25/€18/£15/$25CAN/¥75 Yuan/¥2500 Yen for a review with an image
$10/€7/£6/$10 CAD/¥70 Yuan/¥1110 Yen for a review without an image
Filter by:
MitoBrilliant™ 646 produced excellent results!.
By
Jessica Cale on 11/20/2023
Species: Human
Fixed-cell image of mitochondria stained with MitoBrilliant™ 646:Dermal fibroblast cells were incubated with MitoBrilliant™ 646 (100 nM) for 1 hour at 37°C, fixed with ice-cold acetone-methanol (1:1) and counterstained with Hoechst 33342. Image was taken using an Echo Revolve microscope using a 20x objective. Scale bar = 20 µm.
MitoBrilliant™ 646 produced excellent results as both a live and fixed cell stain. As a live cell stain MitoBrilliant™ 646 produced a stable signal within 20 minutes. For use as fixed-cell stain optimal conditions were found to be a 1-hour incubation in live cells followed by fixation with ice-cold acetone-methanol.
Protocols for MitoBrilliant™ 646
The following protocol features additional information for the use of MitoBrilliant™ 646 (Cat. No. 7700).
Literature in this Area
Tocris offers the following scientific literature in this area to showcase our products. We invite you to request* your copy today!
*Please note that Tocris will only send literature to established scientific business / institute addresses.
MitoBrilliant Research Product Guide
This product guide provides a background, protocols and data from use in different research applications for our Mitobrilliant™ fluorescent mitochondrial probes:
- MitoBrilliant™ 646
- MitoBrilliant™ Live 646
- MitoBrilliant™ Live 549
